AS5800 10GE Multiservice Switch

ASCENT AS5800 Series is a full 10GE Top-of-Rack switches designed for high-performance computing, modern data centers, and advanced campus networks. Built with advanced hardware architecture and the BDROS software platform, the AS5800 Series delivers exceptional scalability, rich routing capabilities, and industry-leading reliability. The 1U AS5800 platform supports up to 2.56 Tbps switching capacity with options for 48 × 10GE ports + 2 × 40GE ports + 4 × 100GE uplinks or a 72 × 10GE configuration, meeting diverse deployment needs from server access to aggregation. With high-performance L2/L3/L4 wire-speed forwarding, the switch integrates IPv6, VPN, security, traffic analysis, and virtualization services, enhanced by mechanisms such as continuous forwarding, graceful restart, and comprehensive loop protection—ensuring stable, non-interruptive operation of the switching fabric. AS5800 Series incorporates the GreenTouch and Smart@CHIP energy-optimized architectures, achieving power consumption below 200W while maintaining top-tier performance. The series includes models AS5800-24X2C and AS5864HB, offering flexible deployment options for demanding data-center, carrier-grade, and enterprise-scale networks requiring high throughput and long-term operational stability.

· Makes full use of each link in the physical device cluster

· Based on the advanced distribution mechanism and efficient cross-physical link aggregation function

· Realizes single IP management, greatly improving the networking efficiency and lowering operating costs

· Supports BVSS, which can virtualize multiple physical devices into a single logical element

· The advanced hardware infrastructure design realizes the level-based packet schedule and packet protection

· Supports IEEE 802.1x, Radius and BDTacacs+

· Supports perfect ring detection mechanism

· Supports port isolation within the same VLAN, DHCP-Snooping, and IP + MAC + Port binding

· Supports the IPv6 protocol suite, IPv6 neighbor discovery, ICMPv6, path MTU discovery, DHCPv6, etc

· Data Center Level High-reliability

Product Characteristics

Item		Unit	Description
			AS5800-24X2C	AS5864HB
Interface			24-Port 10G/GE SFP+ 2-Port 100G/40G QSFP28	48-Port 10G/GE SFP+ 2-Port 40G QSFP+ 4-Port 100G/40G QSFP28
Console			1 RJ45 console, 1 MGMT	1 RJ45 console, 1 MGMT
Backplane		Gbps	880	1920
Forwarding Rate		Mpps	660	1440
Chassis	Dimensions(WxDxH)	mm	440x300x44	440x300x44
	Weight(Empty)	kg	6.1	8.8
Package	Dimensions(WxDxH)	mm	576x448x94	616x488x140
	Weight	kg	7.1	10
Power Consumption	No-Load	W	45	102
	Full-Load	W	70	147
Power Supply (Hot-Swap)	AC: 100-240, 50Hz±10%	V	2	2
Power Status Monitoring			Support	Support
Total Output BTU (1000BTU/H=293W)			238.91	501.71
Fan Number			4	4
Noise@25(dBA)		°C	57	57
MTBF(H)			>200,000	>200,000
Forwarding Mode			Store-forward	Store-forward
Flash		MB	4096	64
DRAM		MB	2048	1024
MAC		K	128	64
Jumbo Frame		K	9	16
Routing Table	IPv4	K	16	16
	Ipv6	K	8	8
ARP Table	IPv4	K	16	16
	Ipv6	K	8	2
Total SVI		K	1	1

Features

Item	Description
VLAN	4K Active VLAN, QinQ & Selective QinQ, GVRP, Private VLAN, Voice-VLAN
Spanning Tree	802.1D (STP) 802.1W (RSTP) and 802.1S (MSTP) BPDU guard, root guard and loopback guard
Multicast	PIM-DM(S5864HB) PIM-SM/SSM IGMP v1/v2/v3 IGMP Snooping IGMP Fast Leave MVR, IGMP filter
IPV4	Static routing, RIP v1/v2 OSPF, BGP, PBR, ECMP BFD for OSPF, BGP
Ipv6	ICMPv6, DHCPv6, ACLv6 and IPv6 Telnet IPv6 neighbor discovery, Path MTU discovery MLD snooping IPv6 Static Routing, RIPng, OSPFv3, BGP4+ Manual tunnel, ISATAP tunnel, 6 to 4 tunnel
QoS	CAR, HQoS, MAC/IP/TCP/UDP/ VLAN/ COS/ DSCP/ TOS based QoS 802.1P/ DSCP priority re- labeling, SP, WRR, and “SP+WRR”, Tail-Drop WRED, ﬂow monitoring and traffc shaping
Security	Port isolation, Port security, and “IP+MAC+port” binding, MAC sticky DHCP Snooping and option 82, DAI & I P source guard, PPPoE+ IEEE 802.1x, AAA, Radius and BDTacacs+ L2/L3/L4 ACL ﬂow identification and filtration Anti-attack from DDoS, TCP’s SYN Flood, UDP Flood, etc Broadcast/multicast/unknown unicast storm-control MD5, SHA-256, RSA-1024, AES256, etc
DHCP	DHCP server/relay/client DHCP snooping/option82
Reliability	Static/LACP link aggregation Interface backup BVSS virtual-stacking EAPS and ERPS URPF, LLDP ISSU VRRP 1+1 power backup
Management	Console, Telnet, SSH v1/2, HTTP, HTTPS SNMP v1/v2/v3, RMON TFTP, FTP, SFTP NTP, SPAN, RSPAN Syslog
Environment	Operating Temperature/Humidity: 0 to 50°C ,10%-90% non-condensing Storage Temperature/Humidity: -20 to 70°C , 5%-95% non-condensing
Certification	CE, FCC, ROHS
Accessories	Power cord, rackmount kits, console cable
