AP WFA-186W

Ascent’s WFA-186W is a dual-band 2x2 MU-MIMO 802.11ax wall plate Wi-Fi AP, which is designed for apartment and hotel that require premium performance. The product supports 802.11ax 2.4G/ 5G Wi-Fi access and can provide up to 2.974Gbps aggregated data rates. It helps you to establish the high speed and stable wireless network. You can access to internet with the phone, pad or laptop in any place. The enhanced transmission power and receive sensitivity make it deliver the high throughput and reliable coverage required. WFA-186W has perfect compatibility. It works with most wireless terminals to build a high capacity Wi-Fi network. The product supports the QSDK and OpenWiFi development platform. This is easy for the user to devselop the applications according to their customization requirement. The product supports PoE power supply. At the same time it can supply the 802.3af PoE PSE for the other device. The universal bracket makes it easy to adapt to the 86 type box in different regions.

·         Support wall mounting with universal bracket

·         Support 2.4G 2x2/ 40MHz Wi-Fi (802.11b/ g/ n/ ac/ ax), up to 574Mbps link rate

·         Support 5G 2x2/ 160MHz Wi-Fi (802.11a/ n/ ac/ ax), up to 2.4Gbps link rate

·         Support BLE 5.1/ Zigbee

·         2 x Integrated dual-band antennas

·         1 x Integrated Bluetooth antenna

·         1 x GE WAN with 802.3 bt PoE (PD)

** Operates with 802.3af PSE with restricted functions

·         4x RJ45 GbE LAN, one with 802.3af PoE (PSE)

·         1 x Reset button on the side

·         1x RBG LEDs for visual indication

·         Support OpenWiFi development platform


Item

Unit

Technical Parameters

Dimension (W x D x H)

mm

180 × 89.5 × 29.3

Weight

g

280, without bracket

Installation


Wall mounting

LEDs


1 x RBG LED (Software definition)

Interface


1 x GE WAN with 802.3 bt PoE(PD)

4x RJ45 GbE LAN, one with 802.3af PoE(PSE)

1 x Reset Button


Input Voltage

V

42.5 to 57 , 802.3bt PoE (PD), with LAN port supporting 802.3af PoE(PSE)

37 to 57, 802.3 af PoE (PD), with restricted functions




Power Consumption

W

< 12, without 802.3af PoE (PSE)

Environmental Specification

Temperature

°C

Operation: 0 to +40 Storage: -40 to +70

Operating Humidity

%

5% to 95% (non-condensing)

Elevations

kPa

86 to 106 altitude

Dustproof and Waterproof


IP30

Safety


NRTL Listed 62368-1 (US & CA)

CB with IEC/EN 62368-1 (Basic safety certificate for worldwide marketing)

GB 9254-2008 (Class B of Product), EN55032, CISPR 32:2010, EN55024, CISPR 24:2010

RoHS 2011/65/EU Compliant (RoHS 11 Compliant, No Pb)

WEEE 2002/96/EC Recyclable Materials Requirements



Reliability

MTBF


> 300,000 Hours

Telcordia SR-332, Reliability Prediction Procedures for Electronic Equipment, Issue 3, Method 1, Case 3, GB/GC (Ground Benign, Controlled) environment, 25°C ambient temperature. Steady state, not including software failure.



AFR


AFR (Annualized Failure Rate) < 1.5% (in continuous operation)


Chipset

SoC


Qualcomm Chipset (IPQ5018)

Flash

MB

128 NAND Flash

DDR

MB

512 DDR3 RAM

Wi-Fi Interface

Operating Frequency

GHz

2.4G radio:2.4000 to 2.4835


5G radio:5.150 to 5.250,5.250 to 5.350,5.470 to 5.725, 5.725 to 5.850


Maximum Transmit Power (per chain)

dBm

2.4G radio:18@MCS0; 18@MCS7; 17@MCS9; 16@MCS11



5G radio:19@MCS0; 19@MCS7; 18@MCS9; 17@MCS11

Data Rate

Mbps

802.11b: 1, 2, 5.5, and 11

802.11g: 6, 9, 12, 18, 24, 36, 48, and 54

802.11a: 6, 9, 12, 18, 24, 36, 48 and 54

802.11n HT20/ HT40: MCS0 to MCS15

802.11ac VHT20/VHT40/VHT80: MCS0 to MCS9

802.11ax HE20/ HE40/HE80/HE160: MSC0 to MCS11



Receive Sensitivity

dBm

802.11g:  -90@6Mbps

-74@54Mbps



802.11n:


HT20

HT40

MCS0/8/16

-90

-87

MCS7/15

-71

-68


802.11a:  -90@6Mbps

-74@54Mbps


802.11ac:


VHT20

VHT40

VHT80

MCS0

-90

-87

-84

MCS8

-67

-64

-61

MCS9


-61

-58

802.11ax:


HE20

HE40

HE80

HE160

MCS0

-90

-87

-84

-81

MCS11

-60

-57

-54

-51

Antenna Pattern (Built-in Antennas)


Frequency(MHz)    2400 to 2500             4940 to 5850

Polarization             Vertical/Horizontal  Vertical/Horizontal

Gain(dBi)                  >3                                >3
