10G SFP+ CWDM 2733 10 km

Ascent’s SFPP-AT-LP-XXXX-10 transceivers are designed expressly for high-speed communication applications that require rates up to 11.3 Gb/s. They are designed to be compliant with the SFF-8472 SFP+ MSA. The module is suitable for data links up to 10 km in distance over a 9/125 µm single mode fiber. ASCENT SFP+ transceivers provide a unique enhanced digital diagnostic monitoring interface which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power, and transceiver supply voltage. It also defines a sophisticated system of alarm and warning flags which alerts end users when particular operating parameters are outside of a factory set normal range.

· Support data rate up to 11.3Gb/s

· Hot-Pluggable SFP Footprint and Single LC Connector

· Up to 10km reach for G.652 SMF

· 1270nm DFB Transmitter and PIN receiver for SFPP-LP-2733-10

· 1330nm DFB Transmitter and PIN receiver for SFPP-LP-3327-10

· Temperature Range:

Commercial:0°C ~ +70°C

Industrial:-40°C ~ +85°C

· Compliant with SFF-8431

· Compliant with SFF-8432

· Compliant with SFF-8472

· Compliant with IEEE802.3ae

Absolute Maximum Ratings

Parameter	Symbol	Min	Typ.	Max	Unit	Note
Storage Temperature	T_S	-40		+85	°C
Maximum Supply Voltage	V_CC	-0.5		3.6	V
Operating Relative Humidity	RH			95	%

Recommended Operating Conditions

Parameter	Symbol	Min	Typ.	Max	Unit	Note
Operating Case Temperature	T_op	0	-	70	°C	Commercial
	T_op	-40	-	85	°C	Industrial
Power Supply Voltage	V_CC	3.13	3.3	3.47	V
Data Rate	BR	-	10.3125	11.3	Gbps
Transmission Distance	TD	-	-	10	km
Coupled Fiber	Single-mode fiber					9/125 µm SMF

Optical Characteristics

Parameter	Symbol	Min	Typ.	Max	Unit	Note
Data Rate			10.3125	11.3	Gbps
Transmitter
Center Wavelength Range	λ_C	1260	1270	1280	nm	SFPP-LP-2733-10
		1320	1330	1340		SFPP-LP-3327-10
Spectral Width (-20dB)	∆λ			1	nm
Side Mode Suppression Ratio	SMSR	30			dB
Average Output Power	Pout	-6		-1	dBm	1
Extinction Ratio	ER	3.5			dB
Average Power of OFF Transmitter	Poff			-30	dBm
Relative Intensity Noise	RIN			-128	dB/Hz	2
Receiver
Wavelength Range	λ_C	1320	1330	1340	nm	SFPP-LP-2733-10
		1260	1270	1280	nm	SFPP-LP-3327-10
Receiver Sensitivity	Pmin			-14.4	dBm	3
Receiver Overload	Pmax	0.5			dBm
LOS De-Assert	LOSD			-18	dBm
LOS Assert	LOSA	-30			dBm
LOS-Hysteresis	Phys	0.5		6	dB

Notes:

1. Output is coupled into a 9/125um SMF.

2. 12dB reflection.

3. Measured with worst ER, BER less than 1E-12 and PRBS 2³¹-1 at 10.3125Gbps.

Electrical Characteristics(TOP = Tc, Vcc = 3.135 to 3.465 Volts)

Parameter	Symbol	Min	Typ.	Max	Unit	Note
Supply Voltage	Vcc	3.135		3.465	V
Supply Current(Commercial)	Icc			300	mA
Supply Current(Industrial)	Icc			450	mA
Power Consumption(Commercial)	P			1.0	W
Power Consumption(Industrial)	P			1.5	W
Transmitter
CML Inputs(Differential)	Vin	150		1200	mVpp	1
Input Impedance(Differential)	Zin	85	100	115	ohm
TX_DIS Disable		2		Vcc+0.3	V
TX_DIS Enable		0		0.8	V
TX_FAULT Fault		2		Vcc+0.3	V
TX_FAULT Normal		0		0.5	V
Receiver
CML Outputs (Differential)	Vout	350		700	mVpp
Output Impedance (Differential)	Zout	85	100	115	Ohm
RX_LOS LOS		2		Vcc+0.3	V
RX_LOS Normal		0		0.8	V
MOD_DEF (0:2) VoH		2.5			V
MOD_DEF (0:2) VoL		0		0.5	V

Note:

1. CML logic, internally AC coupled.

2. Loss Of Signal is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.

Timing Characteristics

Parameter	Symbol	Min	Typ.	Max	Unit	Note
TX_Disable Assert Time	t_off			100	us
TX_Disable Negate Time	t_on			2	ms
Time to Initialize Include Reset of TX_FAULT	t_int			300	ms
TX_FAULT from Fault to Assertion	t_fault			100	us
TX_Disable Time to Start Reset	t_reset	10			us
Receiver Loss of Signal Assert Time	T_A,RX_LOS			100	us
Receiver Loss of Signal Deassert Time	T_d,RX_LOS			100	us
Rate-Select Chage Time	t_ratesel			10	us
Serial ID Clock Time	t_serial-clock			100	kHz
