AS2108 Switch

ACT AS2100 series Optical Fiber Fast Ethernet Switch is the economical series of high performance L2 switches, which provide Network Operators and Services Providers with the cost effective access layer for the Fast Ethernet P2P services in Fiber to The Home/Business (FTTH & FTTB) networks.

• Complied with IEEE802.3 10Base-T Ethernet, IEEE802.3u 100Base-TX and 100Base-FX fast Ethernet.

• High performance L2 switching

• 7 10/100M auto-negotiable UTP ports and 1 100Mbps SFP port

• Auto negotiation function allows UTP port to auto select 10M or 100M, and Full Duplex or Half Duplex.

• Supports Active Ethernet technology with Fast Ethernet subscriber lines

• UTP port supports MDI/MDI-X auto crossover

• 1.8Gbps high performance memory bandwidth

• Intuitive Front Panel LED indicator

• Low Power consumption to save maintenance and services cost

AS2108 Optical Fiber Fast Ethernet Switch

Standards	IEEE802.3 10Base‑T Ethernet IEEE802.3u 100Base‑TX and 100Base‑FX Fast Ethernet ANSI/IEEE STD 802.3 10/100M auto‑negotiated
Protocol	CSMA/CD
MAC Address Table	1K
Data Transmitting Rate	Ethernet: 10Mbps (Half Duplex) 20Mbps (Full Duplex) Fast Ethernet: 100Mbps (Half Duplex) 200Mbps (Full Duplex) Cable
Ports	7 RJ‑45, 10/100Mbps auto‑negotiable ports; 1 SFP port
Shelf manager	SNMP (Simple Network Management Protocol), CLI (Command Line Interface)
Power	100 to 265 VAC, 50Hz, DC 5V 1A
Operating temperature	0~50 °C optimal performance 15~35 °C
Storage temperature	‑25~70 °C
Relative humidity	5% to 90% no condensation
Weight	0.5kg
Ship weight	0.7kg

		AS2108E
Maximum # of 10/100M TX ports		7 TX
Maximum # of 10/100M SFP ports		1 SFP
Combo TX/SFP 1G ports		0
Backplane bandwidth, bps		1.8G
Physical size (WxDxH)		160×83×25mm
Power consumption		5W
