Interface

Port

1-Port Console(RJ45)

1-Port USB2.0

1-Port Gigabit RJ45/SFP combo WAN

8-Port Gigabit RJ45 LAN

Port Console(RJ45)

1-Port USB2.0

1-Port 10G SFP+ WAN

2-Port Gigabit RJ45 WAN 2-Port Gigabit SFP WAN

8-Port Gigabit RJ45 LAN

Button

Mode/Reset

Mode/Reset

Performance

User Capacity

3K

25K

AP Capacity

128 to 256

256 to 1028

Flash

4GB

16GB

DRAM

1GB

4GB

DHCP Table

2K

2K

ARP Table

10K

60K

VLAN

4K

4K

Apperance

Chassis

Dimensions (WxDxH)

440mm x 180mm x 44mm

440mm x 180mm x 44mm

Weight (empty)

2.3Kg

2.3Kg

Package

Dimensions (WxDxH)

500mm x 320mm x 80mm

500mm x 320mm x 80mm

Weight

3.3Kg

3.3Kg

Power Supply

AC 100 to 240V 50/60Hz

AC 100 to 240V 50/60Hz

Consumption

No-Load(W)

12

32

Full-Load(W)

20

50

Working Temperature

0°C to 50°C

0°C to 50°C

Operating Humidity

10%~90%

(non condensing)

10%~90%

(non condensing)

IP Protocol

Direct IP connection, static route

DHCP Server/Client/Relay

NTP Server

FTP Server

L2 or L3 forwarding between AC and external network

AC Function

Switching load from troubled AC to another normal AC (The switch over policy can be set)

Port redundancy: multi-port binding

Connecting AP/AC via L3 security tunnel

Centralized, distributive and hybrid exchanges of L2 services

Inner-AC or inter-AC roaming

Centralized forwarding

Forwarding all services after being centralized on AC

Distributive forwarding

Forwarding some AP or SSID services on a thin AP locally

RTLS

Standard

802.11 a/b/g/n/ac/ax

802.11 a/b/g/n/ac/ax

802.11i, 802.11e

802.3, 802.3ab, 802.3u

802.3x, 802.3z, ARP, Reverse ARP

multi-LAN ARP/Proxy ARP

STP/802.1Q L2 forwarding

RFC791 IP, RFC792 ICMP, RFC793 TCP, RFC768 UDP

RFC854 Telnet, RFC1542 BOOTP

RFC1191 Path MTU Discovery

RF management

Automatic channel

Static channel configuration

Automatic channel configuration when AP is powered

Automatic channel configuration when AP is running

To set an automatic channel choice list

Automatic transmitting power

To set the static transmitting power

The automatic transmitting power for coverage remedy

The STA-based automatic transmitting power to improve the throughput

Automatic rate

The STA-based automatic rate choice

To limit the maximum transmitting rate

AAA

RADIUS Client

Multi-domain configuration of the authentication server

Connection of active and standby authentication/charging servers

Isolation of the authentication server and the charging server

PPPoE authentication

Portal authentication

AAA accounting

Security

Open system

WEP

WPA/WPA2 PSK

802.1x

802.11i

WAPI

DDOS prevention

ACL

Wireless IPS/IDS

Illegal AP detection

Illegal terminal checkup

Isolation of users’ services

Whitelist

Static/dynamic blacklist

URL filter

Management

Pallas cloud platform

Local interconnection based on WEB/SSH

Remote control via SNMP access

Uniform network management via OMC

SNMP v2/v3

MIB-II(RFC1213), which is based on TCP/IP Internet management base

RFC1537, which is a developing protocol of MIB-II

RFC1643

ISO/IEC 8802-11:1999

IEEE802.11b

ISO/IEC 8802-11:1999/Amd 1:2000

MIB that is defined by IEEE 802.11g and IEEE 802.11i

QoS

User’s flow control

The domain-based flow control (taking VLAN or SSID as the configuration domain)

User-level flow control or flow control based on the contract information of the Radius server

Service priority

802.11e, which provides different services according to session’s priority

To map users’ QoS levels according to SSID

802.1p and L2 packet’s priority mapping

Load balance and control

AP/AC interconnection based on priority and load

Load balance between adjacent APs on the basis of user quantity and flow
