AM130C Indoor Client
The AC130C Series is an EOC (Ethernet Over Coax) slave device leveraging the HomePlug AV solution for Ethernet access over coaxial cables. It operates alongside an EOC master, also based on the HomePlug AV solution, to establish a two-layer Ethernet data transmission channel on CATV coax cables, providing Ethernet access services via existing coax cable networks. This series utilizes the Mstar chipset solution, featuring high anti-jamming capabilities powered by OFDM technology. It operates within the 7.5 to 65MHz low-frequency band for EOC signals. A built-in high-isolation filter functions as a CATV RF and EOC signal mixer, allowing EOC signals and CATV signals (87MHz to 1GHz) to coexist on the same cable without interference. The PHY layer achieves speeds of up to 600Mbps, while the MAC layer delivers throughput of up to 320Mbps. The AC130C Series also offers a Wi-Fi version based on the MTK chipset solution, compliant with 802.11 b/g/n technical standards. Equipped with two external antennas, it supports 2.4GHz wireless signals, providing strong penetration and broad coverage. This ensures efficient and secure data transmission for users.
EoC Client with 4FE&1FE
· Low-frequency modulation EOC terminal, HomePlug AV solution, using MSE510CE and MTK7628NN
chips
· 7.5 to 65Mhz frequency for EOC signals, no influence on CATV Service
· PHY Layer speed 600Mbps (AC134) or 500Mbps (AC131)
· Support data encryption
· 4*100M auto-negotiation Ethernet port (AC134) or 1*100M auto-negotiation Ethernet port (AC131)
· Support the isolation of slave
· Support Port-based VLAN and 802.1q VLAN
· Support bandwidth limited
· Support QOS configuration based on slave port or VLAN
· Support broadcast storm control
· Support data packages count
· Automatically get configurations from EOC Master when Newly connected with powered on
· Support WEB,CLI and SNMP management
· Support on-line upgrading
Item | Parameter | Unit | Description | ||
Interface & Indicator | RF Interface | 1*TV(RF signal) OUTPUT, metric/inch F connector 1*CABLE(MIX)INPUT, metric/inch F connector | |||
Ethernet Interface | M | 4*10/100 auto-negotiation, RJ45 | |||
Power Interface | V | 1*DC12 power supply interface | |||
LED Indicators | 1*power indicator 1*system indicator 1C*ABLE indicator LAN indicator(each Ethernet port has 1 indicator) | ||||
Performance Parameters | RF Parameters | Frequency | MHz | 7.5 to 65 | |
Output Level | dBuv | 110 ± 5 | |||
Receive Sensibility | dB | -65 | |||
Return Loss | dB | >16 | |||
Output Impedance | Ω | 75 | |||
Transmission | PHY Layer | Mbps | 600 | ||
Throughput on MAC Layer | Mbps | 320 | |||
Modulation Mode | OFDM– 2690-carriers 4096/1024/256/64/16/8-QAM, QPSK, BPSK, ROBO | ||||
Working Mode | TDMA/CSMA | ||||
Encryption Mode | AES-128 | ||||
Standard | EOC Standard | IEEE P1901(Draft) HomePlug AV | |||
Ethernet Standard | IEEE 802.3, IEEE 802.3x, IEEE 802.3u IEEE802.1P, IEEE802.1Q | ||||
Software | Network Management | WEB, CLI, SNMP | |||
Software Features | VLAN, QOS, Bandwidth Control, Broadcast storm limitation | ||||
Physical Features | Power Supply & Consumption | Power Adapter | V | 12 DC 0.5A | |
Power Consumption | W | <5 | |||
Dimension (L)x(W)x(H) | mm | 160 x139.5 x 28.5 | |||
Weight | kg | 0.3 | |||
Environment Attribute | Work Temperature | °C | 0 to 55 | ||
Stock Temperature | °C | -30 to 60 | |||
Work Humidity | % | 10 to 90, non-condensation | |||
Stock Humidity | % | 5 to 95, non-condensation | |||
Item | Parameter | Unit | Description |
Performance Parameters | Operating Mode | Router or bridge | |
WIFI Antenna | 2 external antennas, 1 built in antennas | ||
Throughput | Mbps | IEEE 802.11b: 11 IEEE 802.11g: 54 IEEE 802.11n: 300 | |
Frequency | GHz | 2.412 to 2.472 | |
Channel | 13*Channel, 1,2,3,4,5,6,7,8,9,10,11,12,13 | ||
Modulation | Mbps | 11b:DSSS:DBPSK(1),DQPSK(2), CCK(5.5/11) 11g:OFDM:BPSK(6/9),QPSK(12/18),16QAM(24/36),Q64QAM(48/54) 11n: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM. | |
Receive Sensitivity | dBm | 11 Mbps:≤-89 | |
54 Mbps:≤-76 | |||
HT20 MCS7:≤-72 | |||
HT40 MCS7:≤-68 | |||
RF Output Lever | dBm | 802.11n:16.5 | |
Encryption Mode | AES, TKIP, WPA, WPA2, WPA-PSK/WPA2-PSK |
EoC Client with 1FE
Item | Parameter | Unit | Description | |
Interface & Indicator | RF Interface | 1*CABLE(MIX)INPUT, metric/inch F connector | ||
Ethernet Interface | M | 1*10/100 auto-negotiation, RJ45 | ||
Power Interface | V | 1*DC12 power supply interface | ||
LED Indicators | 1 x power indicator 1 x SYS indicator 1 x CABLE indicator 1 x LAN indicator | |||
Performance Parameters | RF Parameters | Frequency | MHz | 7.5 to 65 |
Output Level | dBuv | 110 ± 5 | ||
Receive Sensibility | dB | -65 | ||
Return Loss | dB | >16 | ||
Output Impedance | Ω | 75 | ||
Transmission | PHY Layer | Mbps | 500 | |
Throughput on MAC Layer | Mbps | 320 | ||
Modulation Mode | OFDM– 2690-carriers 4096/1024/256/64/16/8-QAM, QPSK, BPSK, ROBO | |||
Working Mode | TDMA/CSMA | |||
Encryption Mode | AES-128 | |||
Standard | EOC Standard | IEEE P1901(Draft) HomePlug AV | ||
Ethernet Standard | IEEE 802.3, IEEE 802.3x, IEEE 802.3u IEEE802.1P, IEEE802.1Q | |||
Software | Network Management | WEB, CLI, SNMP | ||
Software Features | VLAN, QOS, Bandwidth Control, Broadcast storm limitation | |||
Physical Features | Power Supply & Consumption | Power Adapter | V | 12 DC 0.5A |
Power Consumption | W | <3 | ||
Dimension (L)x(W)x(H) | mm | 78 x 78 x 25 | ||
Weight | kg | 0.1 | ||
Environment Attribute | Work Temperature | °C | 0 to 50 | |
Stock Temperature | °C | -40 to 85 | ||
Work Humidity | % | 10 to 90, non-condensation | ||
Stock Humidity | % | 5 to 95, non-condensation | ||
